RoastMaster™60
Designed for artisanal roasting operations with a throughput of up to 240kg per hour. RoastMaster™ 60 delivers a consistently high quality of flavour whilst offering a unique blend of flexibility and automation.
Key Features
-
Highly convective heat transfer for consistent roasting
Proven drum technology
-
Flexible modular burner for accurate profile control
Consistent and reproducible roasts
-
Fully automated safety system in the roasting drum
For complete operational safety
-
Data and trend monitoring for roast profile analysis
Process visualisation
-
Optional hot air recirculation with variable controls
Saves up to 30% energy
-
Global process and technology expertise and support
Trusted partner for your business
Special Offer for IKAWA’s Network
Available on quotation
Follow the link to connect with Bühler’s specialists team and receive the IKAWA exclusive pricing in a personalised quote.
Your Benefits
Optimum flavour development
Develop consistently high quality coffee with RoastMaster’s modular burner and superior drum delivering precise, uniform and reproducible roasts.
Total control of the roasting process
Create sophisticated roasts your customers will love with the easy to use, flexible, multi-step profile controls for automated and consistent output.
Enhanced cooling efficiency
Make your day-to-day roasting operations a competitive advantage. Produce up to 70kg per hour with consistent results batch-after-batch.
Technical Information
-
Dimensions:
Roaster only: 5m x 2.8m x 3.2m
Roaster with accessories: 9.7m x 9.7m x 5.6m
Estimated Capacity:
25kg - 8-10m - 35-55kg p/h
40kg - 10-12m - 45-60kg p/h
60kg - 12-20m - 290kg-190kg p
RoastMaster™60 Coffee Roaster includes:
Hopper with sight glass for green coffee beans
Roasting drum design for a good product mix
Combustion chamber with compact Weishaupt gas burner
Separate hot and cold air fans; cyclone with receptacle for chaff separation; round bed cooler for uniform and fast cooling of the roasted coffee beans
Integrated control cabinet with integrated PLC control unit
Inlet hot air temperature sensor
Product temperature sensor
Two-step drum speed control
Variable hot air fan speed control
Negative Pressure sensor
Burner Modulation
Third party connection: Cropster, Artisan
Data storage
Recommended quotation will also include:
Feeding System
Emission control treatment (after burner):
To burn particulate matter and volatiles in the exhaust gases
Modular burner for better energy efficiency
Integrated into machine control
Total installed electrical load 15kW
Thermal Energy:
Main burner: 200kW
LPG flow rate: 8Nm3/h
Natural gas flowrate: 20 Nm3/h
Afterburner: 350kW
LPG flow rate: 16Nm3/h
Natural gas flowrate: 35 Nm3/h
Compressed air at 6bar: 0.7m3/h
Water at 4bar: 100l/min
-
Estimated delivery time is based on specifications of the order and is confirmation upon consultation.
Delivery and installation will be quoted based on your location
Subject to site readiness for installation (speak to your Bühler Account Manager for consultation on how “site ready” is defined)
-
Product Variants:
Closed Cycle or Open Cycle (hot air recirculation system)
LPG/Natural gas
50/60 HZ
220/400 V
CE/UL certified
Destoner and evacuation
Catalysator
Climate control for control cabinet
Extra chaff collector
Water Buffer Unit
Grinder
Color sorters
Speak to Account Manager during your initial consultation about Bühler’s full service equipment.
